S160T Sand Filter Series Parts

Details:
Hayward Pool Products Part Number ECX270861
1⁄4 Inch Bottom Mount
Used On Hayward Super StarClear Cartridge Filter Series
Used On Hayward MicroClear Vertical Grid D.E. Filter Series
Used On Hayward Perflex EC30 EC40 EC40AC Series Extended-Cycle D.E. Filter
Used On Hayward ProSeries Plus Sand Filter Series
Used On Hayward ProSeries Sand Filter Series
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward ProSeries S140T S144T Sand Filter Series
Used On Hayward ProSeries S180T, S210T, S220T, S220T2, S230T, S244T, S244T2, S270T Sand Filter Series
Used On Hayward ProSeries S164T S166T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward Swim Pro Sand Filters

Details:
Hayward Pool Products Part Number SX200Z6
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number ECX1642A
Includes Hex Nut, Head Bolt and Washer
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number ECX1077
1⁄4" x 1 1⁄16" O.D. Flat
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward S240 Sand Filter Series
Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number SX160QA
Used On Hayward S160T Sand Filter Series

• See Diagram A

Details:
Hayward Pool Products Part Number SX160Z1
Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number SX200QPAK10
10 Pack
Used On Hayward ProSeries S180T, S210T, S220T, S220T2, S230T, S244T, S244T2, S270T Sand Filter Series

• S180T

Used On Hayward ProSeries S164T S166T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward Swim Pro Sand Filters

Details:
Hayward Pool Products Part Number SX200H
Used On Hayward ProSeries Plus Sand Filter Series

• 2005 and earlier

Used On Hayward ProSeries Sand Filter Series

• 2005 and earlier

Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward ProSeries Top-Mount Sand Filter Series

• 2005 and earlier

Used On Hayward ProSeries S140T S144T Sand Filter Series

• 2005 and earlier

Used On Hayward ProSeries S180T, S210T, S220T, S220T2, S230T, S244T, S244T2, S270T Sand Filter Series

• 2005 and earlier

Used On Hayward ProSeries S164T S166T Sand Filter Series

• 2005 and earlier

Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number ECX1642215
1⁄4" - 20 x 1 3⁄4" Hex Head
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number SX200Z5
1 3⁄16" O.D.
Used On Hayward Super StarClear Cartridge Filter Series
Used On Hayward MicroClear Vertical Grid D.E. Filter Series
Used On Hayward ProSeries Plus Sand Filter Series
Used On Hayward ProSeries Sand Filter Series
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series

Details:
Hayward Pool Products Part Number SX200Z14
1" O.D.
Used On Hayward S240 Sand Filter Series
Used On Hayward S160T Sand Filter Series

• after 1980

Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series

Details:
Hayward Pool Products Part Number SX200Z8A
Includes Cap and Gasket
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward EasyClear C400, 550 Cartridge Filter Series

Details:
Hayward Pool Products Part Number SX200EB
Includes Pipe, O-Ring, Cap and Gasket
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series

Details:
Hayward Pool Products Part Number SX200J
Used On Hayward ProSeries Sand Filter Series

• S210S, S244S

Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward ProSeries Top-Mount Sand Filter Series

• S270T

Used On Hayward ProSeries S180T, S210T, S220T, S220T2, S230T, S244T, S244T2, S270T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series

Details:
Hayward Pool Products Part Number ECX1291
Used On Hayward ProSeries Sand Filter Series
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series

Details:
Hayward Pool Products Part Number SP-1105Z4
1 1/2 Mpt X 1 1/2 Barbed
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward Perflex EC30 EC40 EC40AC Series Extended-Cycle D.E. Filter
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward ProSeries S164T S166T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward Swim Pro Sand Filters

Details:
Hayward Pool Products Part Number SP-1091Z2PAK2
1 1/2 Mpt X 1 1/2 Barbed - Set of 2
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward ProSeries S164T S166T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward Swim Pro Sand Filters

Details:
Hayward Pool Products Part Number SX201Z1
33 Inch
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series

Details:
Hayward Pool Products Part Number SX160Z4
26 Inch
Used On Hayward S160T Sand Filter Series

• 1700 Systems

Details:
Hayward Pool Products Part Number SX160Z3
31 Inch
Used On Hayward S160T Sand Filter Series

• 1500 Systems

Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward Swim Pro Sand Filters

Details:
Hayward Pool Products Part Number ECX18028
1.5 Inch Hose
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward Perflex EC30 EC40 EC40AC Series Extended-Cycle D.E. Filter
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward ProSeries S164T S166T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward Swim Pro Sand Filters

Details:
Hayward Pool Products Part Number ECX1161Z2
with Washers
Used On Hayward Perflex EC65, EC65A, EC75, EC75A Extended-Cycle D.E. Filter
Used On Hayward ProSeries Sand Filter Series
Used On Hayward S240 Sand Filter Series
Used On Hayward S200 Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S160T Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward S245T S190T GM195 GM225 GM245 Sand Filter Series
Used On Hayward ASL Filter Series Cartridge Filter Series

Details:
Hayward Pool Products Part Number SP-1250WA
6 feet - 14/3 guage
Used On Hayward PowerFlo
Used On Hayward StarClear Cartridge Filter Series

• C Series Systems

Used On Hayward Perflex EC30 EC40 EC40AC Series Extended-Cycle D.E. Filter
Used On Hayward S160T Sand Filter Series
Used On Hayward ASL Filter Series Cartridge Filter Series
Used On Hayward Swim Pro Sand Filters
